Products Features
1, PLC control, servo system drive, stable and efficient low failure rate;
2, Cutting speed up to 200 cuts/min;
3, High cutting accuracy, cutting error +/-1mm;
4, Adopting inverter technology, energy and power saving;
5, Adopting high quality electric eye detection system, automatic stopping when abnormality ;
6, Touch screen control panel, easy to operate;
7, Equipment safety cover built-in iron mesh, outside observation window with plexiglass, safety protection function;
Parameters
| Item | Technical parameters |
|---|---|
| Cutting range | L=100-400mm, W=200-500mm, H=80-120mm |
| Cutting speed | 200 cut/min |
| Control system | PLC programming control, servo driving system, touch screen operation panel |
| Feeding manner | Servo driving, Synchronous belt positioning transmission |
| Cut-off manner | 360° rotary motion continuous cutting |
| Cutting accuracy | ±1mm |
| Paper head/tail removal | PLC controlling, Touch screen operation, removal width 15-60mm |
| Sharpening system | Automatic knife sharpening, touch screen setting parameters, |
| Rotary knife diameter | ￠610mm |
| Air pressure | 0.5-0.6 Mpa; knife sharpening air pressure 0.2mpa |
| （Provide by user） | |
| Power supply | 380V/50Hz |
| Machine power | 10KW |
| Machine size | L2000mm×W1700mm×H1900mm |
